Description 2000-1204 2-conductor through terminal block;1 mm²;for Ex e II and Ex i applications;blue
Quick and easy connections are guaranteed with this through terminal block (item number 2000-1204). Strip lengths must be between 9 and 11 mm when connecting conductors to this through terminal block. Whether for use in industry or building installations, our rail-mount through terminal blocks allow you to quickly and securely connect electrical conductors. They’re perfect for either classic through-wiring or distributing potential, depending on the variant. Featuring conductor terminals along with Push-in CAGE CLAMP®, this product delivers reliable performance. Push-in CAGE CLAMP® technology provides a universal connection solution for all conductor types. It allows both solid and fine-stranded conductors with ferrules to be inserted directly into the clamping point without the need for tools. The item's dimensions are (3.5 x 48.5 x 39.5) mm (width x height x depth). Depending on the conductor type, this through terminal block is ideal for conductor cross sections ranging from 0.14 mm² to 1.5 mm².
This through rail-mount terminal block is operated with an operating tool. Our TOPJOB® S rail-mount terminal blocks offer more than just secure electrical connections in different industrial applications and modern building installations. They also offer the perfect solution for every need: lever, push-button, or operating slot. This product is designed for specific Ex applications (please refer to the product datasheet).
Main attributes 2000-1204 2-conductor through terminal block;1 mm²;for Ex e II and Ex i applications;blue
Connection 1
Actuation type
Operating tool
Connectable conductor materials
Copper
Connection technology
Push-in CAGE CLAMP®
Fine-stranded conductor
0.14 … 1.5 mm² / 24 … 16 AWG
Fine-stranded conductor; with ferrule; push-in termination
0.5 … 0.75 mm² / 20 … 18 AWG
Fine-stranded conductor; with insulated ferrule
0.14 … 0.75 mm² / 24 … 18 AWG
Nominal cross-section
1 mm²
Note (conductor cross-section)
Depending on the conductor characteristic, a conductor with a smaller cross-section can also be inserted via push-in termination.
Solid conductor
0.14 … 1.5 mm² / 24 … 16 AWG
Solid conductor; push-in termination
0.5 … 1.5 mm² / 20 … 16 AWG
Strip length
9 … 11 mm
Wiring direction
Front-entry wiring
Connection data
Clamping units
2
Number of jumper slots
2
Number of levels
1
Total number of potentials
1
Environmental requirements
Continuous operating temperature
-60 … +105 °C
Processing temperature
-35 … +85 °C
Environmental Testing (Environmental Conditions)
Acceleration
5g (highest test level used for all axes)
Extended test scope: Monitoring for contact faults/interruptions
Passed
Extended test scope: Voltage drop measurement before and after each axis
Passed
Frequency
f1 = 5 Hz to f2 = 150 Hz
Function test with noise-like vibration
Test passed according to Section 8 of the standard
Monitoring for contact faults/interruptions
Passed
Number of shocks per axis
3 pos. und 3 neg.
Shock duration
30 ms
Shock form
Half sine
Shock test
Test passed according to Section 10 of the standard
Simulated service life test through increased levels of noise-like vibration
Test passed according to Section 9 of the standard
Spectrum/Installation location
Service life test, Category 1, Class A/B
Test directions
X, Y and Z axes
Test duration per axis
5 h
Test procedure (Railway applications – Roll
DIN EN 61373 (VDE 0115-0106):2011-04
Test specification Railway applications – Rolling stock – Electronic equipment
DIN EN 50155 (VDE 0115-200):2022-06
Vibration and shock stress for rolling stock equipment
Passed
Voltage drop measurement before and after each axis
Passed
Material data
Color
blue
Fire load
0.079 MJ
Flammability class per UL94
V0
Insulation material (main housing)
Polyamide (PA66)
Material group
I
Weight
3.6 g
Mechanical data
Marking level
Center/side marking
Mounting type
DIN-35 rail
Physical data
Depth
39.5 mm
Depth from upper-edge of DIN-rail
32.9 mm
Height
48.5 mm
Width
3.5 mm
