Description 870-682 3-conductor through terminal block;2.5 mm²;lateral marker slots;orange
Our through terminal block (item number 870-682) is designed for seamless electrical installations. Ensure that the strip lengths are between 6 and 7 mm when connecting conductors to this through terminal block. Whether in industrial or building applications, our rail-mount through terminal blocks are the perfect solution to quickly and securely connect electrical conductors. Depending on the variant, you can use them for either typical through-wiring or potential distribution. This product incorporates conductor terminals and utilizes CAGE CLAMP®. Our reliable and maintenance-free CAGE CLAMP® connection makes it easy to connect all types of conductors without having to prepare the conductor. For example, you don't need to crimp ferrules. Depending on the conductor type, this through terminal block is ideal for conductor cross sections ranging from 0.08 mm² to 2.5 mm².
An operating tool is used to operate this mini rail-mount terminal block.
Main attributes 870-682 3-conductor through terminal block;2.5 mm²;lateral marker slots;orange
Connection 1
Actuation type
Operating tool
Connectable conductor materials
Copper
Connection technology
CAGE CLAMP®
Fine-stranded conductor
0.08 … 4 mm² / 28 … 12 AWG
Fine-stranded conductor; with insulated ferrule
0.08 … 1.5 mm² / 28 … 14 AWG
Solid conductor
0.08 … 2.5 mm² / 28 … 12 AWG
Strip length
6 … 7 mm
Wiring direction
Front-entry wiring
Connection data
Clamping units
3
Number of levels
1
Total number of potentials
1
Environmental requirements
Continuous operating temperature
-60 … +105 °C
Processing temperature
-35 … +85 °C
Material data
Color
orange
Fire load
0.101 MJ
Flammability class per UL94
V0
Insulation material (main housing)
Polyamide (PA66)
Material group
I
Weight
5.9 g
Mechanical data
Design
horizontal type
Marking level
Side marking
Mounting type
DIN-35 rail
Physical data
Depth from upper-edge of DIN-rail
27.5 mm
Height
49 mm
Width
5 mm
