Article: 757-443/000-010
Brand: Wago
5,189.74 грн.
Payment
Delivery
The nearest branch addresses can be viewed on the map.
from
150.00 грн.
Pickup (Kyiv)
For free
Description 757-443/000-010 M8 sensor/actuator box;4-way;3-pole
- M8 sensor/actuator box, 4-way
- 3-pole (1 signal per contact)
- Cable length: 5 and 10 m
- Green LED operating indicator
- Yellow LED status indicator
- incl. marking strips (WMB markers can also be used)
- incl. M8 protective caps (2 pcs)
Main attributes 757-443/000-010 M8 sensor/actuator box;4-way;3-pole
Connection data
Cable design
Wire cross-section: 0.34 mm²; Wire cross-section (2): 0.75 mm²
Connection technology: inputs/outputs
4 x M8 socket; 3-pole
Connection technology: trunk cable
1 x Fixed connecting cable
Length of connection cable
10 m
Strip length
100 mm
Wire colors
white, green, yellow, gray, brown, blue
Environmental requirements
Ambient (operating) temperature (dynamic)
-5 … +80 °C
Ambient (operating) temperature (static)
-40 … +90 °C
Ambient temperature (operation)
-25 … +80 °C
Note on protection type
72 h at a depth of 1 m under water per EN 60529 in the fully locked position with its plugs or protective caps
Pollution degree
3 per VDE 0110
Protection type
IP68
Shock resistance
per IEC 60068-2-27
Vibration resistance
per IEC 60068-2-6
Material data
Bending radius
10 x cable diameter (min.) for flexible application
Encapsulation
Fully encapsulated with conformal coating (UL 94 V0)
Halogen-free
Yes
Housing material
PA 66 (UL 94 V0); RAL 7035; silicon and halogen free
Material properties of the connections
Contact: CuSn, nickel base-coat plating and 0.8 μm gold-plated; Threaded bush: die-cast Zn, nickel-plated; Seal: Viton; 50 mating cycles
Sheath material
PUR
Sheathed cable color
black
Mechanical data
Mounting type
Screw mounting
Weight
660 g
Physical data
Depth
117 mm
Height
20 mm
Width
30 mm
Technical data
Contact resistance (max.)
0.01 Ω
Current carrying capacity (signal connections)
2 A
Current carrying capacity (supply connections)
6 A
Functionally separated potential groups
Kontakt/Kontakt
Indicators
LED yellow: Signal status (1 x per contact); LED (U) green: Sensor/actuator box status
Insulation resistance
>109 Ω
Rated value of electrical isolation
500 V
Signal characteristics
PNP
Supply voltage
10 … 30 VDC; Rated voltage: 32 V ~ rms
